Optical Substrates
> Schott Glass Slabs Substrates Rods
|
| |
| Schott BF33 -Borofloat 33 Glass Substrate Window |
| P/N: | BF33 Series |
| Introduction: | Schott BF33 -Borofloat 33 Glass Substrate Window |
|
|
|
|
|
| |
| |
| Schott D263 Borosilicate Glass Substrate B-Grade |
| P/N: | D263 Series |
| Introduction: | Schott D 263 is a low alkali borosilicate glass that is produced by melting the purest raw materials. As such, it is very resistant to chemical attack. D 263, with its specific properties and large range of different thicknesses with tight tolerances, is exceptionally well suited for a number of applications including: liquid crystal displays, optoelectronics, touch control panels, sensors, electroluminescent displays and solar cells. Due to a special down draw production process, D 263 glass sheets are marked by fire-polished surfaces; this glass type can be used without ground and polished surfaces.
Click here to download Schott D 263 Thin Borosilicate Glass datasheet |
|
|
| P/N |
Keywords |
Unit Price |
Available |
Generate Quotation |
| D263-B-S-02500250-0030 |
25.0x25.0xT0.3mm,D263,20-10 S/D,Ra<20A,MOQ25pcs |
S$20.00/pc |
In stock |
Add to Request List |
| D263-B-S-02500250-0040 |
25.0x25.0xT0.4mm,D263,20-10 S/D,Ra<20A,MOQ25pcs |
S$22.00/pc |
In stock |
Add to Request List |
| D263-B-S-07500250-0030 |
75.0x25.0xT0.3mm,D263,20-10S/D,Ra<20A,MOQ10pcs |
S$50.00/pc |
In stock |
Add to Request List |
| D263-B-S-07500250-0040 |
75.0x25.0xT0.4mm,D263,20-10 S/D,Ra<20A,MOQ10pcs |
S$55.00/pc |
In stock |
Add to Request List |
| D263-C-S-05000800-0050-MOQ50pcs |
50.0x80.0xT0.50mm,D263t,40-20 S/D,Ra<20A,MOQ50pcs |
S$30.00/pc |
In stock |
Add to Request List |
| D263-B-S-12701270-0030 |
127.0x127.0xT0.3mm,D263,20-10 S/D,Ra<20A |
S$150.00/pc |
In stock |
Add to Request List |
| D263-B-S-12701270-0040 |
127.0x127.0xT0.4mm,D263,20-10 S/D,Ra<20A |
S$160.00/pc |
In stock |
Add to Request List |
| D263-C-S-18601600-0050 |
186.0x160.0xT0.50mm,D263t,40-20 S/D,Ra<20A |
S$155.00/pc |
In stock |
Add to Request List |
| D263-C-S-00500050-0030 |
5.0x5.0xT0.300mm,D263,40-20 S/D DSP,MOQ100pcs |
S$1.50/pc |
In stock |
Add to Request List |
| D263-C-S-00500050-0040 |
5.0x5.0xT0.4mm,D263,40-20 S/D DSP,MOQ500pcs |
S$00.65/pc |
Call us |
Add to Request List |
| D263-C-R1016-0050 |
Dia101.6xT0.50mm,D263t,40-20 S/D DSP,MOQ50pcs |
S$65.00/pc |
Call us |
Add to Request List |
| D263-C-R1524-0050 |
Dia152.4xT0.50mm,D263t,40-20 S/D DSP,MOQ25pcs |
S$115.00/pc |
Call us |
Add to Request List |
|
|
| |
| |
| Schott B270 Glass Substrate B-grade |
| P/N: | B270-B Series |
| Introduction: | To meet a variety of different market demands, SCHOTT offers its
well-known B 270™ crown glass in sheet glass form.This is the improved version of sola-lime glass, ultra-wite.
B 270™, manufactured by the up-draw method, offers high stability
with respect to solarization in combination with high transmission in the
visible wavelength range. It has a fire-polished surface and high
chemical stability. |
|
|
| P/N |
Keywords |
Unit Price |
Available |
Generate Quotation |
| B270-B-10001000-0150 |
100x100xT1.5mm, Schott B270, 20/10 S/D, Ra<20A |
S$110.00/pc |
In stock |
Add to Request List |
| B270-B-10001000-0200 |
100x100xT2.0mm, Schott B270, 20/10 S/D, Ra<20A |
S$110.00/pc |
Call us |
Add to Request List |
| B270-B-10001000-0230 |
100x100xT2.3mm, Schott B270, 20/10 S/D, Ra<20A |
S$110.00/pc |
In stock |
Add to Request List |
| B270-B-12701270-0230 |
127x127xT2.3mm, Schott B270, 20/10 S/D, Ra<20A |
S$155.00/pc |
In stock |
Add to Request List |
|
|
| |
| |
| Schott B270 Glass Substrate C-Grade |
| P/N: | B270-C Series |
| Introduction: | To meet a variety of different market demands, SCHOTT offers its
well-known B 270™ crown glass in sheet glass form.This is the improved version of sola-lime glass, ultra-wite.
B 270™, manufactured by the up-draw method, offers high stability
with respect to solarization in combination with high transmission in the
visible wavelength range. It has a fire-polished surface and high
chemical stability. |
|
|
| P/N |
Keywords |
Unit Price |
Available |
Generate Quotation |
| B270-C-R-0254-0300 |
Dia25.4xT3.0mm,Schott B270 glass,40/20 S/D DSP |
S$14.50/pc |
In stock |
Add to Request List |
| B270-C-R-0500-0100 |
Dia50.0xT1.0mm,Schott B270 glass,40/20 S/D DSP |
S$19.00/pc |
In stock |
Add to Request List |
| B270-C-R-0500-0200 |
Dia50.0xT2.0mm,Schott B270 glass,40/20 S/D DSP |
S$22.00/pc |
In stock |
Add to Request List |
| B270-C-R-0500-0300 |
Dia50.0xT3.0mm,Schott B270 glass,40/20 S/D DSP |
S$28.00/pc |
In stock |
Add to Request List |
| B270-C-R-0508-0100 |
Dia50.8xT1.0mm,Schott B270 glass,40/20 S/D DSP |
S$19.00/pc |
In stock |
Add to Request List |
| B270-C-R-0508-0200 |
Dia50.8xT2.0mm,Schott B270 glass,40/20 S/D DSP |
S$22.00/pc |
In stock |
Add to Request List |
| B270-C-R-2032-0150 |
Dia203.2xT1.50mm,B270,40-20 S/D,Ra<10A |
S$290.00/pc |
In stock |
Add to Request List |
| B270-C-S-03000300-0200 |
30.0x30.0xT2.0mm,Schott B270 glass,40/20 S/D DSP |
S$12.00/pc |
In stock |
Add to Request List |
| B270-C-S-05400470-0215 |
54.0x47.0xT2.15mm,Schott B270 glass,40/20 S/D DSP |
S$25.00/pc |
In stock |
Add to Request List |
| B270-C-S-10001000-0100 |
100.0x100.0xT1.0mm,Schott B270,40/20 S/D DSP |
S$32.00/pc |
In stock |
Add to Request List |
| B270-C-S-10001000-0200 |
100.0x100.0xT2.0mm,Schott B270,40-20 S/D DSP |
S$45.00/pc |
In stock |
Add to Request List |
| B270-C-S-10001000-0230 |
100.0x100.0xT2.3mm, Schott B270, 40/20 S/D DSP |
S$65.00/pc |
In stock |
Add to Request List |
| B270-C-S-10001000-0320 |
100x100xT3.2mm, Schott B270 glass,40-20 S/D DSP |
S$90.00/pc |
In stock |
Add to Request List |
| B270-C-S-12701270-0230 |
127.0x127.0xT2.3mm,Schott B270,40-20 S/D DSP |
S$105.00/pc |
In stock |
Add to Request List |
| B270-C-S-28201710-0300 |
282.0x171.0xT3.0mm,Schott B270 glass,40-20 S/D DSP |
S$280.00/pc |
In stock |
Add to Request List |
| B270-C-S-30002150-0600 |
300.0x215.0xT6.0mm,Schott B270 glass,40-20 S/D DSP |
S$480.00/pc |
In stock |
Add to Request List |
| B270-C-S-40602580-0100 |
406.0x258.0xT1.0mm,Schott B270 glass,40-20 S/D DSP |
S$270.00/pc |
In stock |
Add to Request List |
| B270-C-S-54803640-0550 |
548.0x364.0xT5.5mm,Schott B270 glass,40-20 S/D DSP |
S$520.00/pc |
Call us |
Add to Request List |
|
|
| |
| |
| Schott B270 Glass Substrates / Slabs (D-Grade) |
| P/N: | B270-D Series |
| Introduction: | To meet a variety of different market demands, SCHOTT offers its
well-known B 270™ crown glass in sheet glass form.This is the improved version of sola-lime glass, ultra-wite.
B 270™, manufactured by the up-draw method, offers high stability
with respect to solarization in combination with high transmission in the
visible wavelength range. It has a fire-polished surface and high
chemical stability. |
|
|
| P/N |
Keywords |
Unit Price |
Available |
Generate Quotation |
| B270-D-S10000940-0100 |
100x94xT1.0mm,Schott B270,80-50 S/D,MOQ10pcs |
S$30.00/pc |
In stock |
Add to Request List |
| B270-D-R-0254-0100 |
Dia25.4xT1.0mm,Schott B270,80-50 S/D DSP,MOQ50pcs |
S$3.50/pc |
Call us |
Add to Request List |
| B270-D-R-0300-0100 |
Dia30.0xT1.0mm,Schott B270,80-50 S/D DSP,MOQ50pcs |
S$3.80/pc |
Call us |
Add to Request List |
| B270-D-R-0350-0100 |
Dia35.0xT1.0mm,Schott B270,80-50 S/D DSP,MOQ50pcs |
S$4.90/pc |
Call us |
Add to Request List |
| B270-D-R-0400-0100 |
Dia40.0xT1.0mm,Schott B270,80-50 S/D DSP,MOQ50pcs |
S$5.50/pc |
Call us |
Add to Request List |
| B270-D-R-0500-0100 |
Dia50.0xT1.0mm,Schott B270,80-50 S/D DSP,MOQ50pcs |
S$8.50/pc |
Call us |
Add to Request List |
| B270-D-R-1524-0150 |
Dia152.4xT1.5mm,Schott B270,60-40 S/D DSP |
S$165.00/pc |
In stock |
Add to Request List |
| B270-D-S-00500050-0100 |
5.0x5.0xT1.0mm,B270,DSP,60-40 S/D,MOQ200pcs |
S$1.50/pc |
In stock |
Add to Request List |
| B270-D-S-01000050-0100 |
10.0x5.0xT1.0mm,Schott B270,60-40 S/D,MOQ100pcs |
S$2.60/pc |
In stock |
Add to Request List |
| B270-D-S-01200120-0100 |
12.0x12.0xT1.0mm,Schott B270,60-40 S/D,MOQ100pcs |
S$3.00/pc |
In stock |
Add to Request List |
| B270-D-S-02000050-0100 |
20.0x5.0xT1.0mm,Schott B270,60-40 S/D,MOQ100pcs |
S$2.80/pc |
In stock |
Add to Request List |
| B270-D-S-02000100-0100 |
20.0x10.0xT1.0mm,Schott B270,60-40 S/D,MOQ100pcs |
S$2.80/pc |
In stock |
Add to Request List |
| B270-D-S-02000200-0050C |
20.0x20.0xT0.5mm,B270,Cube,60-40 S/D DSP |
S$20.00/pc |
In stock |
Add to Request List |
| B270-D-S-02000200-0065C |
20.0x20.0xT0.65mm,B270,Cube,60-40 S/D DSP |
S$20.00/pc |
In stock |
Add to Request List |
| B270-D-S-02000200-0100 |
20.0x20.0xT1.0mm,Schott B270,60-40 S/D,MOQ100pcs |
S$3.50/pc |
In stock |
Add to Request List |
| B270-D-S-02000200-0100C |
20.0x20.0xT1.0mm,B270,Cube,60-40 S/D DSP |
S$20.00/pc |
In stock |
Add to Request List |
| B270-D-S02500250-0055 |
25.0x25.0xT0.55mm,Schott B270,60-40 S/D DSP |
S$5.50/pc |
In stock |
Add to Request List |
| B270-D-S02500250-0100 |
25.0x25.0xT1.0mm,Schott B270,80-50 S/D,MOQ25pcs |
S$4.50/pc |
In stock |
Add to Request List |
| B270-D-S-02500250-0200 |
25.0x25.0xT2.0mm,Schott B270,80-50 S/D,MOQ100pcs |
S$5.20/pc |
In stock |
Add to Request List |
| B270-D-S-03500250-0100 |
35.0x25.0xT1.0mm,Schott B270,80-50 S/D,MOQ50pcs |
S$4.50/pc |
In stock |
Add to Request List |
| B270-D-S-05000500-0100 |
50.0x50.0xT1.0mm,Schott B270,80-50 S/D,MOQ50pcs |
S$7.40/pc |
In stock |
Add to Request List |
| B270-D-S-07500250-0100 |
75.0x25.0xT1.0mm,Schott B270,80-50 S/D,MOQ10pcs |
S$7.00/pc |
In stock |
Add to Request List |
| B270-D-S-07500500-0100 |
75.0x50.0xT1.0mm,Schott B270,80-50 S/D,MOQ50pcs |
S$12.00/pc |
In stock |
Add to Request List |
| B270-D-S-07620762-0100 |
76.2x76.2xT1.0mm,Schott B270,60-40 S/D,MOQ25pcs |
S$13.00/pc |
In stock |
Add to Request List |
| B270-D-S-08000400-0110 |
80.0x40.0xT1.1mm,Schott B270,80-50 S/D,MOQ50pcs |
S$7.00/pc |
In stock |
Add to Request List |
| B270-D-S-08000200-0100 |
80.0x20.0xT1.0mm,Schott B270,80-50 S/D,MOQ50pcs |
S$5.00/pc |
In stock |
Add to Request List |
| B270-D-S-08600600-0100 |
86.0x60.0xT1.0mm,Schott B270,80-50 S/D,MOQ30pcs |
S$9.20/pc |
In stock |
Add to Request List |
| B270-D-S-08600860-0100 |
86.0x86.0xT1.0mm,Schott B270,80-50 S/D,MOQ50pcs |
S$9.50/pc |
In stock |
Add to Request List |
| B270-D-S-09700950-0300 |
97.0x95.0xT3.0mm,B270,60-40 S/D DSP,MOQ2pcs |
S$95.00/pc |
In stock |
Add to Request List |
| B270-D-S-10000300-0100 |
100.0x30.0xT1.0mm,Schott B270,80-50 S/D,MOQ100pcs |
S$7.90/pc |
In stock |
Add to Request List |
| B270-D-S-10001000-0100 |
100x100xT1.0mm,Schott B270,80-50 S/D,MOQ10pcs |
S$12.00/pc |
In stock |
Add to Request List |
| B270-D-S-10001000-0200 |
100x100xT2.0mm,Schott B270,80-50 S/D,MOQ10pcs |
S$14.00/pc |
In stock |
Add to Request List |
| B270-D-S-10300090-0200C1 |
103.0x9.0xT2.0mm;B270;80-50 S/D DSP;MOQ2pcs |
S$85.00/pc |
In stock |
Add to Request List |
| B270-D-S-10300110-0200C1.5 |
103.0x11.0xT2.0mm;B270;80-50 S/D DSP;MOQ8pcs |
S$65.00/pc |
Call us |
Add to Request List |
| B270-D-S-12501250-0110 |
125.0x125.0xT1.1mm,Schott B270,80-50 S/D DSP |
S$22.00/pc |
In stock |
Add to Request List |
| B270-D-S-12701270-0110 |
127.0x127.0xT1.1mm,Schott B270,80-50 S/D DSP |
S$22.00/pc |
In stock |
Add to Request List |
| B270-D-S20000200-0400SLAB |
200x20x4mm,B270,slab,6-surface polished,60-40 S/D |
S$280.00/pc |
Call us |
Add to Request List |
| B270-D-S25002500-0300H3x4 |
250x250xT3.0mm,B270,60-40 S/D DSP,Hole dia3.0mmx4 |
S$385.00/pc |
In stock |
Add to Request List |
| B270-D-S-29702100-0100 |
297.0x210.0xT1.0mm,Schott B270,60-40 S/D,MOQ10pcs |
S$95.00/pc |
In stock |
Add to Request List |
| B270-D-S-30002800-0300 |
300.0x280.0xT3.0mm,B270,60-40 S/D DSP |
S$230.00/pc |
In stock |
Add to Request List |
|
|
| |
| |
| Standard Soda Lime Glass Substrates |
| P/N: | SL Series |
| Introduction: | Soda lime glass?aalso referred to as soda glass or soda lime silica glass?ais the most widely used type of glass in the world. Known for its excellent formability, durability, and cost-efficiency, soda lime glass is used in countless everyday applications, from window glass to bottles, jars, and products made of glass. This type of glass is made primarily from glass raw materials such as silica (sand), sodium carbonate, and calcium oxide, all of which influence the chemical composition of glass and its physical properties.
The typical composition of soda lime glass includes:
about 70 - 75% silica(SiO₂)
about 12 - 15% soda(Na₂O)
about 10% lime(CaO)
These components of glass are fused at high temperatures during the formation of glass. The chemical formula of glass may vary slightly depending on the specific application, but soda and lime remain the defining constituents. The chemical formula of limestone, primarily CaCO₃, plays a role as a lime source. When heated, it decomposes to provide calcium oxide.
This glass composition gives soda lime its distinctive properties: moderate chemical resistance, ease of melting, and high optical clarity. The addition of other materials such as alumina, magnesia, or potassium glass can enhance certain mechanical properties of glass like hardness and thermal stability.
Characteristics and properties of soda lime glass
Understanding the characteristics of glass is essential for industries relying on performance and safety. Some core soda lime glass properties include:
Density of glass: approximately 2.5 g/cm³
Glass density and mass of glass affect how it behaves under stress and its suitability for various structures.
Hardness of glass: ranges from 5 to 6 on the Mohs scale
Moderate bending strength of glass
Thermal conductivity: ~1.0W/m.K
Thermal expansion coefficient: ~9x10⁻⁶/K
Softening point: ~720 Celsius degree
Its glass chemical composition provides transparency, resistance to mild acids, and excellent shaping capabilities. However, the strength of glass varies with treatment; for example, chemically toughened glass or tempered glass shows dramatically improved performance under load. |
|
|
|
|
|
| |
| |
| Schott SF57 Glass Rods |
| P/N: | SF57 Series |
| Introduction: | Schott glass material, N-S57
nd=1.84666
|
|
|
| P/N |
Keywords |
Unit Price |
Available |
Generate Quotation |
| SF57-R10-30-NIR |
Dia10.0xL30.0mm,SF57,Glass Rod,DAR@700-1300nm |
S$420.00/pc |
In stock |
Add to Request List |
| SF57-R10-50-NIR |
Dia10.0xL50.0mm,SF57,Glass Rod,DAR@700-1300nm |
S$460.00/pc |
Call us |
Add to Request List |
| SF57-R10-100-NIR |
Dia10.0xL100.0mm,SF57,Glass Rod,DAR@700-1300nm |
S$550.00/pc |
In stock |
Add to Request List |
| SF57-R10-150-NIR |
DIA10.0xL150.0mm,SF57 Glass Rod,AR@700-1300nm |
S$780.00/pc |
Call us |
Add to Request List |
| SF57-R10-200-NIR |
DIA10.0xL200.0mm,SF57 Glass Rod,AR@700-1300nm |
S$990.00/pc |
Call us |
Add to Request List |
| SF57-R0254-0500-VIS |
Dia25.4xL50.0mm,SF57,Glass Rod,DAR@400-700nm |
S$720.00/pc |
Call us |
Add to Request List |
| SF57-R0254-1000-VIS |
Dia25.4xL100.0mm,SF57,Glass Rod,DAR@400-700nm |
S$985.00/pc |
Call us |
Add to Request List |
|
|
| |
| |
| Schott N-SF19 Glass Material Block |
| P/N: | SF19 Series |
| Introduction: | Schott material, N-SF19, 667331.290.
Refractive index 1.667
Abbe number: 33.12 |
|
|
|
|
|
| |
Optical Substrates
Quartz Substrates Plates Wafers
Optical Crystals Ceramics
